Ortofon 2M Mono Moving Magnet Cartridge

Ortofon 2M Mono Moving Magnet Cartridge

Name: Ortofon 2M Mono Moving Magnet Cartridge
Brand: Ortofon
SKU: 2MMONOCART
Price: 729.00 NZD
Availability: InStock

$729.00

Sold out

Product variants

The 2M Mono features an improved engine, which provides a high level of sonic accuracy. The stylus' tip features a R 18µm Nude Spherical diamond that is an optimal solution for playing mono microgroove LP vinyl records. The cartridge body is manufactured from Hopelex, which ensures high rigidity while eliminating unwanted resonances.

The 2M Mono uses a strapped output to deliver the same output signal from both sets of pole pins. This effectively eliminates the need for mono-specific equipment, making it possible to enjoy true mono reproduction on any stereo playback system.

The 2M Series provides excellent compatibility when used in an assortment of playback systems and with a wide variety of phono preamps.

Quantity

Free Shipping for orders $500+

Ask a question

Specifications

Output voltage at 1000 Hz, 5cm/sec. - 4 mV
Frequency response - 20-20.000 Hz + 3 / - 1 dB
Tracking ability at 315Hz at recommended tracking force - 70 µm
Compliance, dynamic, lateral - 18 µm/mN
Stylus type - Nude Spherical
Stylus tip radius - R18 µm
Tracking force range - 1.6-2.0 g (16-20 mN)
Tracking force, recommended - 1.8 g (18 mN)
Tracking angle - 20°
Internal impedance, DC resistance - 700 Ohm
Internal inductance - 350 mH
Recommended load resistance - 47 kOhm
Recommended load capacitance - 150-300 pF
Cartridge colour, body/stylus - Black/White
Cartridge weight without screws - 7.2 g

It is an incredibly cost effective addition to my system which unlocks a massive quantity of mono music for my enjoyment.

Your sound matters

Stylus

Embark on an Elevated Mono Experience with the 2M Mono Cartridge. Designed to bring out the best in your mono microgroove LP vinyl records, it features a stylus tipped with an R 18µm Nude Spherical diamond. This engineered feature is an optimal solution for playing mono microgroove LP vinyl records and is ideal for achieving exceptional playback quality and capturing the essence of vintage mono soundscapes.

Output

The 2M Mono uses a strapped output to deliver the same output signal from both sets of pole pins. This effectively eliminates the need for mono-specific equipment, making it possible to enjoy true mono reproduction on any stereo playback system.

Free turntable setup

We carefully set up every turntable and cartridge we sell. So if you're new to turntables or have decades of experience, you know you'll be getting the most enjoyment from your system. You can be safe in the knowledge that you can take your turntable home, plug it straight in and start enjoying good music without any worry of something being setup incorrectly.

If you own a significant amount of mono records, you’ll not regret investing in a true mono cartridge like the 2M Mono. If you’re new to mono records and just getting started, you’ve got a whole world to explore. Particularly as stereo began its journey to the mainstream through the 1960s, many records were released as both stereo and mono versions.
